Description:

Specifications

• Compatibility: CX Series
• Lift Height Max at Pivot Pin: 87.80 in (2,230 mm)
• Clearance Level: 84.30 in (2,141 mm)
• Clearance Dumped: 67.20 in (1,706 mm)
• Reach at Max Height: 31.50 in (800 mm)
• Dump Angle Max: 53°
• Reach at Ground: 59.80 in (1,520 mm)
• Rollback Angle Max: 35°
• Digging Depth: 3.90 in (99 mm)
• Height Max in Carry Position: 40 in (1,016 mm)
• Bucket Depth: 19.90 in (505 mm)
• Bucket Size: 50 in (1,270 mm)
• Lift Capacity to Full Height: 1,092 lb (495 kg)
• Breakout Force at Pivot Pin: 1,843 lb (836 kg)
• Bucket Rollback Force at Ground: 1,416 lb (642 kg)
• Relief Valve Setting: 2,275 psi (156.85 bar)
• Rated Flow: 6.86 gpm (26 lpm)
• Bucket Capacity Heaped: 7.80 ft³ (0.22 m³)
• Weight: 605 lb (274 kg)
