*Freight and PDI not included in price

Description:

• Ariens AX 223CC engine with electric start
• Strong cast-iron gear case
• Compact, user-friendly design with Auto-Turn for easy operation

Specifications:

• Title: Compact 24 Auto
• Model Number: 920029

Power Train:

• Engine: Ariens AX®
• Starting System: 120v / Electric
• Steering: Auto-Turn
• Drive Type: Disc-O-matic
• Speeds: 6 Forward/2 Reverse

Tires:

• Size: 15 In / 38.1cm
• Type: Directional Snow Tread

Clearing Specs:

• Clearing Width (in/cm): 24 In / 60.9cm
• Housing Height: 20 In / 50.7cm
• Throwing Distance: 3 ft - 40 ft
• Chute Rotation: 2.5x Quick Turn
• Chute Turning Radius: 205 degrees
• Deflector Control: In-Dash Lever
• Stage Type: Two Stage
• Auger Diameter: 11 In / 27.9cm
• Auger Type: Steel Serrated
• Impeller Profile: Steel 3 Blade
• Impeller Diameter: 12 In / 30.4cm
• Skid Shoes: Steel Reversible
• Scraper Bar: Steel Adjustable
• Gear Case: Cast Iron

Dimensions:

• Length: 53.3 In / 135.3cm
• Width: 26.4 In / 67cm
• Height: 44 In / 111.7cm
• Weight (Assembled): 187 lb / 84.8 kg

Warranties:

• Product Warranty: 3 years residential use. 90 days commercial use
• Gear Case Warranty: 5 Year Consumer, 1 Year Commercial

Accessories:

• Features at a Glance:
• Light Type: Halogen
• Handwarmers: Optional
• Remote Deflector Control: Standard
• Drift Cutters: Optional
• One Hand Interlock: Standard
