Description:

SE models offer additional comfort and convenience features: hydrostatic transmission, single hydraulic valve, joystick valve and premium seat.

Features:

Convenience Features

A deluxe suspension seat, PTO cruise, high ground clearance, power steering, tilt steering wheel, center marker, projection light for better night vision, and a one piece engine panel to check service points with ease.

Safety

Wet disc brakes, a sturdy ROPS or Cab, and a secure seatbelt keep you safe. Headlights, safety lights, and a rear work light lets you see attachments and drawbars clearly, even in low-light conditions.

Attractive Options

Dress up your tractor with impressive options. Swap standard tires for turf, industrial, or R14 tires. Add a fuel heater kit, 2nd remote hydraulic valve, or bluetooth speaker kit for comfort and convenience.

Rugged Performance

Dependable, liquid-cooled KIOTI 3-cylinder diesel engine hums with fuel efficiency, ready to take on demanding jobs all day long. Engage the rear differential lock for unflinching traction, then command implements with the push-button hydraulic PTO.

Specification:

Engine:

• Model: 3HT-TH4C
• Manufacturer: KIOTI
• Power: 50.30 hp (37.50 kW)
• Displacement: 111.40 cu. in. (1,826 cc)
• RPM: 2,600 rpm
• Fuel Type: Diesel
• Aspiration: Intercooler
• Fuel Capacity: 12.70 gal (48 L)

Transmission:

• Type: Hydrostatic
• Shuttle: Hydrostatic
• Travel Speeds Forward: 3 Ranges with Infinite Speeds
• Travel Speeds Reverse: 3 Ranges with Infinite Speeds
• Minimum Speed Forward: 1.29 mph (2.08 km/h)
• Maximum Speed Forward: 16.71 mph (26.90 km/h)
• Minimum Speed Reverse: 1.26 mph (2.03 km/h)
• Maximum Speed Reverse: 16.28 mph (26.20 km/h)

PTO (Power Take-Off):

• Type: Independent
• PTO Power: 28.90 hp (21.60 kW)
• Rear Speed: 540 rpm
• Mid Speed: 2,000 rpm

Drive Train:

• Brakes: Wet Multi Disc
• Clutch: None
• Steering: Hydrostatic Power Steering

Hydraulics:

• Pump Type: Gear
• Pump Capacity: 16.50 gpm (62.40 lpm)
• Lift Capacity: 2,716 lb (1,232 kg)

Hitch:

• Type: Three Point
• Category: Category 1
• Control Type: Position
• Lift Capacity: 1,500 lb (680 kg)

Dimensions:

• Length with Hitch: 125.50 in (3,189 mm)
• Width: 62.80 in (1,596 mm)
• Wheelbase Length: 71.30 in (1,810 mm)
• Ground Clearance: 14.50 in (368 mm)
• Front Tread: 49.40 in (1,254 mm)
• Rear Tread: 49.30 in (1,251 mm)
• Turning Radius: 102.80 ft (2,610 m)
• Weight: 3,523 lb (1,598 kg)
• Height: 98.60 in (2,458 mm)
